KDC-X7000DAB
CD-Receiver with DAB+ tuner & Bluetooth Built-in
Key Features
| 4 x 50W Max output power |
| 3 RCA Preout, 4V |
| Dual USB (Front & Rear) |
| iPod / iPhone Direct Control |
| Android MSC / AOA2 compatible |
| TuneinRadio/AUPEO App mode |
| MP3, WMA, AAC, WAV & FLAC playback |
| Bluetooth bult-in, (HFP 1.6 & A2DP) |
| Easy Pairing via USB for Android & Iphone |
| Easy Pairing via NFC |
General Features
| DIN Size | 1 DIN |
| Detachable Faceplate | Yes |
| Rotary Encoder & Control Knob | Yes |
| Music Search function | Yes |
| Accent key | Telephone |
| Back-up Memory | Radio presets |
| Attenuator with Smooth Volume Return | Yes |
| Digital Clock (24H) | Yes |
| All-off Select (20/40/60 minutes) | Yes |
| Built-in Connector | Molex 16 pin |
| Firmware upgreadable | Yes |
Display Features
| Display Type | Liquid Crystal Display (LCD) |
| Display Layout | 13Seg. X 13 Digit / 1,5 line |
| Display Illumination | Variable by RGB LED |
| Variable Illumination | Yes |
| Spectrum Analyzer | 13 Band |
| Dimmer Control | Manual / Set by Timer |
| Dimmer Timer | Yes |
| Brightness control | 0 - 31 steps |
| Demo Mode | Yes |
| Menu text in selectable language | English, Spanish, Russian |
| TAG Language Display | English, Spanish, Russian, Greek & Turkish |
Cosmetics features
| Triangle Illumination | Red |
| Front terminals dust cover | Yes |
| Key illumination | Variable by RGB LED |
| Display illumination | Variable by RGB LED |
| Brightness Control (Key) | 0 - 31 step |
| Dimmer Control (Key) | Manual / Set by Timer |
| Variable color illumination | Yes |
| Lightning bar | Yes |
| Music Synchronized Illumination | Yes |
Tuner Features
| FM Reception | Yes |
| FM Stereo / Mono Selector | Yes |
| AM (MW/LW) Reception | Yes |
| Tuning mode | |
| Presets | 24 Presets (18FM / 3LW / 3MW) |
| Mixed preset memory (FM & AM) | 6 presets |
| Automatic Memory Entry (AME) | Yes |
| Tuner Preset Back-up Memory | Yes |
| Radio Data System | Yes |
| Radio Text Plus | Yes |
| Traffic Information | Yes |
| Local search | Yes |
| AF Regional | Selectable: AF/AF Reg/OFF |
| Auto TP search | Yes |
| Enhanced Other Networks Function (EON) | Yes |
CE DAB tuner features
| DAB+ tuner built-in | Yes |
| Digital Radio Certification Mark | Yes |
| Intelligent seek | Yes |
| Ensemble seek | Yes |
| Tuning mode / Seek mode | Auto1/Auto2/Manual |
| Service preset | 6 ch * 1 bank presets, |
| Auto service memory (AME) | Yes |
| Auto Ensemble Memory (AME) | Yes |
| Service list by alphabet order | Yes |
| Audio interrupt standby by PTY | Yes |
| Audio interrupt standby by announcement | Yes |
| Traffic Information | Yes |
| DAB priority | Yes |
| DAB-DAB/DAB-FM auto switch | Yes |
| DLS (Dynamic Label) | Yes |
| DRC (Dynamic Range Control) | Yes |
| PTY (Programme Type) search | Yes |
| TMC (Traffic Message Channel) support | Yes |
| Antenna power supply on/off switch | Yes |
| DAB antenna included | Yes |
Playable Audio File
CD Features
| CD Text with special Character Support | English, Spanish, Russian, Greek, Turkish |
| D.A.C. processing | 24 bit |
| 0 bit Mute | Yes |
USB Features
| USB terminal | Yes, Front & Rear |
| Dual USB terminals | Yes, 1 Front & 1 Rear |
| USB Type | USB 1.1/USB 2.0 Full Speed |
| Drive Change | Yes |
| Repeat/Scan/Random search | Yes |
| Repeat / Random Play | Yes |
| Resume play | Yes |
| Time code display | Yes |
| 1,5A Smartphone Quick Charge | Yes |
iPod Features
| Made for iPod & iPhone * | Yes |
| USB Direct Control (Audio, 1 wire, Lightning-connector) | |
| Alphabet search | Yes |
| Direct Search | Yes |
| iPod EQ Mode | Yes |
| Control by hand | Yes |
| App & iPod control mode | Yes |
| iAP over Bluetooth | Yes |
| Reverse browsing | Yes |
| Works with iPod Classic * | 80G, 120G & 160G |
| Works with iPod Video * | 5th/6th generation |
| Works with iPod Touch * | 2nd/3rd/4th & 5th*** generation |
| Works with iPod Nano * | 3rd/4th/5th/6th/7th generation |
| Works with iPhone * | 3G, 3GS,4,4S, 5, 5S, 5C, 6, 6Plus |
| Bluetooth Auto Paring for iPhone | Yes |
| Battery charge + power control | Yes |
| 1A current capability | Yes |
| * Always update to latest Apple firmware | |
| ** Apple Lightning - 30 pin adapter required | |
| *** In case of Apple Unit with Lightning Connector only Audio playback | Yes |
Audio Features
| Maximum Output Power | 50W x 4 |
| MOSFET Power IC | Yes |
| Auxiliary input | Front Mini-jack |
| Pre-out | 3 RCA |
| Pre-out Output Level | 4V |
| Subwoofer Reference Level Adj. | Yes |
| 2-Way X'over network | Yes |
| 3-Way x'over (bi-amp connection) | Yes |
| Balance/Fader/Loudness Control | Yes |
| Loudness Control | Off/Low/High |
| Bass Boost Circuit | Off/+1/+2/+3/+4/+5 |
| Equalizer built-in | Yes, 13 band with 8 presets |
| Low- & High-pass Filter | Yes |
| Kenwood Sound Reconstruction | Yes |
| Space Enhancer | Yes |
| Realizer | Yes |
| Drive EQ | Yes |
| Extra EQ | Yes |
| Sound Elevation | Yes |
Bluetooth General Features
| Hands Free Profile (HPF) | V1.6 |
| Hands Free Profile with High Sound Quality | HFP V1.6 |
| Max num. of regist. phones for HFP | 10 phones |
| 2 phones full time connection | Yes |
| Audio Streaming (A2DP) | Yes |
| Serial Port Profile (SPP) | Yes |
| Phonebook Access Profile (PBAP) | Yes |
| Audio/Video Remote Control Profile (AVRCP) | Yes, V 1.5 with Tag browse |
| Wireless Music Browsing (AVRCP 1.5) | Yes |
| Easy pairing function | Yes |
| Easy pairing HFP device | Yes |
| iPhone & Android automatic pairing via USB | Yes |
| Voice Dialing / Siri Eyes Free | Yes |
| Voice Control | Yes |
| Noise Canceller | Yes |
| Echo Canceller | Yes |
| Phone device status display | Yes |
| Signal strength display | Yes |
| Remaining battery display | Yes |
| High-quality noise canceling microphone | (rear wired) |
| Bluetooth firmware upgradeable | Yes |
| * depends on phone model/make | & Kenwood unit |
Connectivity
| iPod Digital Connection (1 Wire) | Yes |
| Front USB & AUX Input | Yes |
| OEM Wired Remote Control ready | Yes |
| DC-Cord | Molex to ISO |
| Power Control (P.CON) wire | Yes |
| 2-way (Tel/Navi) mute wire | Yes |
| FM Antenna Input | |
| DAB Aerial input | |
| External microphone input |
Tuner Specifications
| FM range: 87.5Mhz - 108MHz (50Khz step) | Yes |
| FM Usable Sensitivity | 0.71μV/75ohm (S/N 26dBf) |
| FM Quieting Sensitivity | 2μV/75ohm (S/N 46dBf) |
| FM Frequency Response | 30Hz ~ 15kHz (± 3dB) |
| FM Signal to noise ratio (Mono) | 64dB |
| FM Stereo Separation (1kHz) | 40dB |
| MW range: 531kHz - 1611kHz (9kHz step) | Yes |
| MW Usable Sensitivity | 28.2μV |
| LW range: 153kHz - 279kHz (9kHz step) | Yes |
| LW Usable Sensitivity | 50μV |
DAB Tuner specifications
| L Band - Frequency range | 1452.96MHz - 1490.624MHz |
| Band III - Frequency range | 174.928 MHz - 239.2MHz |
| Mode | I, II, III, IV |
| Sensitivity | - 100dBm |
| Signal to noise ratio | 80dB |
| DAB Aerial Connector Type | SMB |
| Output Voltage | 14.4V (11V to 16V allowable) |
| Maximum Current | < 100 mA |
Codec Specs
| MP3 Format | MPEG 1/2 Audio Layer 3-Files |
| WMA Format | Compliant with Windows Media Audio |
| AAC Format | AAC-LC “.m4a” files |
| WAV Format | RIFF waveform Audio Format (only for LinearPCM) |
| FLAC Format | all FLAC files |
CD Specifications
| Laser Diode | GaAIAs |
| Digital Filter(D/A) | 8 Times Over Sampling |
| Digital/Analogue Converter | 24 Bit |
| Spindle Speed | 500 ~ 200rpm (CLV: 1 times) |
| Wow & Flutter | below measurable limit |
| Frequency Response | 20Hz ~ 20kHz (±1dB) |
| Total Harmonic Distortion | 0.01% (1kHz) |
| Signal to Noise Ratio | 105dB (1kHz) |
| Dynamic Range | 90dB |
| Channel Separation | 85dB |
USB Specifications
| USB Version compatibility | USB 1.1/2.0 full speed |
| File System | FAT 32/16/12 |
| Maximum Supply current | 1000mA |
Audio Specifications
| Maximum Power | 50W x 4 |
| Output Power (DIN45324,+B=14.4v) | 30W x 4 |
| Preout Level | 4000mV / 10kOhm, |
| Preout Impedance | ≤ 600Ohm |
| Speaker Impedance | 4Ohm ~ 8Ohm |
| AUX Frequency Response | 20Hz ~ 20kHz (±1dB) |
| AUX Maximum Input Voltage | 1000mV |
| AUX Input Impedance | 30kOhm |
| Graphical Equalizer | 13-Band |
| G. EQ. Frequency (Hz) | 62,5Hz - 16kHz |
| G. EQ. Gain (dB) | -8/-7/-6/.../-1/0/1/.../6/7/8 |
| High Pass Filter Frequency (Hz) | Through/62/100/120/150/180 |
| Low Pass Filter Frequency (Hz) | 55/85/120/160/Through |
| Subwoofer Level (dB) | -50 dB to +10dB |
Bluetooth specifications
| Technology | bluetooth V2.1+EDR/Bluetooth V3.0 |
| Frequency | 2.402 - 2.48 GHz |
| Output power | +4dBm(max), 0dBm (AVE) power class 2 |
| Maximum range | Line of sight approx. 10 meter |
Accessories
| Release keys | 2 pieces |
| Escutcheon | Yes |
| Installation Sleeve | Yes |
| DC cord (Molex to ISO) | 25 cm |
| DAB antenna | with 3.5 m cable |
| Handsfree Microphone | with 3 m cable |
| Multi-Language Instruction Manual Included | Quick-Guide |
| Manuals Downloadable | Yes |
General Specifications
| Operating voltage | 14.4V (10.5 ~ 16V Allowable) |
| Maximum Current Consumption | 10A |
| Dimensions (WxHxD) | 182 x 53 x 159mm |
| Weight, inclu. sleeve & escutcheon | 1.3 kg |
| Unit weight in individual package | 1.6 kg |
| Operation Temperature Range | -10°C ~ 60°C |
