KFC-T207
  • KFC-T207

Additional Images

KFC-T207

20mm Component Tweeter

DISCONTINUED MODEL

  • Overload Protection System
  • Cross-over Network

Key Features

20mm U.F.L.C. Soft Dome Tweeter
2-way Mounting: Flush/ Surface Mount
Crossover Network in See-through Compact Housing
280W Peak Input Power

Speaker Features

Speaker SystemComponent Tune-up Tweeter
Speaker TypeTweeter
Peak Input Power280W
Rated Input Power65W
Speaker Size20mm
Magnet TypeNeodymium
Overload Protection SystemYes
TerminalsSlide type
Installation CapabillityFlush/ Surface Mount
Cross-over NetworkCrossover Network in See-through Compact Housing

Tweeter Specifications

Peak Input Power280W
Maximum Input Power130W
Rated Input Power65W
Cone Size20mm
Dimensions38 x 38 x 22.7mm
Cone MaterialU.F.L.C. Soft Dome
Magnet TypeNeodymium
Cross-over Frequency4500Hz
Sensitivity90dB
Frequency Response3500Hz ~ 35000Hz
Impedance4Ω
Speaker Weight40gr
Gross Weight500gr
Magnet Weight6.4gr

Cross-over Network Specifications

Cross-over network typePassive network
Crossover Network HousingSee-through Compact Housing
Tweeter Protection CircuitYes

Accessories

BracketFlush mount bracket: 2 pieces
Surface mount bracket: 2 pieces
double tape: 2 pieces
Screw (3x8mm): 4 pieces
Screw (3x16mm): 4 pieces
Screw (4x16mm): 4 pieces
Speed nut (3mm): 4 pieces
M5: 2 pieces
Cross-over network (in line): 2 pieces
